Q10N Gimbal Camera for Drone

Gimbal Camera AI object detection and Tracking Video Q10N is a Professional 3-axis High-precise Gimbal The Q10N gimbal camera is designed with 3-axis stabilization capability, and carries a 10X zoom camera for gimbal drone aerial inspection, surveillance, and search and rescue missions. It has an HD 10X optical zoom camera and a 3-axis high stabilized gimbal , which is able to capture 1080p 30fps video. The captured data are recorded on an onboard TF card. Q10N is controlled by the drone pilot or a secondary individual allowing for an overhead view that can cover a large field of ground quickly and effectively. The 10x optical zoom function of the camera allows you to see every detail of interest in the scene while staying at a distance. 10x Optical Zoom Camera Q10N features a 10x optical zoom lens. It is powered by a 2.48MP 1/3″ SENSOR CMOS module, provides great performance in poor light environments, and has a wide dynamic range of 105dB. This feature is excellent for flying at sunset or sunrise. In the presence of backlight or strong light, the view of the over bright and over dark regions can still be captured at the same time. The camera stabilizer drone gimbal outputs Full HD 1080p (1920×1080) images, and has autofocus — uses a fast focus algorithm with focus time <1s. IP Output with 360 degrees continuous The Q10N gimbal camera supports IP video output and 360 degrees of continuous yaw rotation. The Default IP video output resolution is set at 720P. 3-axis Small Size Gimbal Camera Q10N gimbal camera is a professional 3-axis gimbal zoom camera with high stability, small size, lightweight, and low power consumption. Also known as brushless gimbals, it is suitable for VTOL Drones, helicopters, fixed-wing planes, Multirotor aircraft, and other types of drones. Multi Control Methods The default control method is PWM and Serial port (TTL voltage level). However, you can optionally use SBUS to control it. Using Viewpro software Viewlink you can do TTL control. Control box signal interfaces Q10N Applications Q10N gimbal camera is designed to be used in various fields like public security, electric power lines inspection, control of fire hazards, aerial photography and cinematography, construction sites, and any other industry that can benefit from the usage of drones. Q10N is Compatible with Viewport Q10N gimbal camera is compatible with quick-release connectors. This gives you easy assembly, and plug and play capability. You can just install the quick-release connector on your drone, and use different types of drone camera based on your mission requirements. Q10N Gimbal Camera Dimensions For a comprehensive reading of related products, please visit the Motionew website. FAQ – Q10N Gimbal Camera 1. What are the optical capabilities of the Q10N? The Q10N offers 10x optical zoom with Full HD video output, making it suitable for inspection, monitoring, and aerial surveillance tasks. 2. What stabilization system does this gimbal use? It features a 3-axis self-stabilized gimbal, ensuring smooth and stable footage even under UAV vibrations. 3. Is the Q10N compatible with lightweight drones? Yes. The compact design makes it a good fit for small and medium UAV platforms where weight efficiency is essential. 4. What payment methods are supported for this gimbal? Purchases can be made via major credit cards, PayPal, and international bank transfers. 5. Is OEM customization available for enterprise or bulk orders? Yes. OEM services are offered for clients requiring customized gimbal solutions for specific drone applications. 6. Are user manuals and technical documents provided? Yes. Buyers receive datasheets, user manuals, and integration guides to support deployment.
